Model No.
型號
|
LF-48
|
LF-55
|
LF-60
|
LF-65
|
|
Suitable Material
適合材料
|
LDPE/HDPE
|
LDPE/HDPE
|
LDPE/HDPE
|
LDPE/HDPE
|
|
Screw Diameter(mm)
螺桿直徑
|
48
|
55
|
60
|
65
|
|
Max Screw Speed(r/min)
螺桿轉速
|
96
|
80
|
80
|
80
|
|
Traction Shaft Length(mm)
牽引皮軸長度
|
650
|
650
|
800
|
800
|
|
Max Film Width (mm)
膜寬度
|
570+14x2
|
570+14x2
|
770+14x2
|
770+14x2
|
|
Film Thickness(mm)
膜厚度
|
0.01-0.1
|
0.01-0.1
|
0.01-0.1
|
0.01-0.1
|
|
Max Extrusion(kg/hr)
最大擠出量
|
30
|
45
|
55
|
60
|
|
Ratio of Length to Diameter(mm)
螺桿長徑比
|
32:1
|
31:1
|
33:1
|
32:1
|
|
Die head diameter
模頭直徑
|
200
|
200
|
200
|
200
|
|
Extruder Power(kw)
擠出機功率
|
11
|
11
|
15
|
18.5 or 22
|
|
Traction Motor Power(kw)
牽引電機功率
|
2.2
|
2.2
|
2.2
|
2.2
|
|
Heating Device Power(kw)
加熱裝置功率
|
13.6
|
14.7
|
15.7
|
23.7
|
|
Winder Motor Power（kw）
繞線機電機功率
|
2.2
|
2.2
|
2.2
|
2.2
|
|
CNC Accuracy
數據控制系統精度
|
1000g/+1.5g
|
1000g/+1.5g
|
1000g/+1.5g
|
1000g/+1.5g
|
|
Max winding diameter(mm)
最大纏繞直徑
|
1000
|
1000
|
1000
|
1000
|
|
Over Dimension(mm)
外觀尺寸
|
6600x2200x5370
|
6600x2700x5370
|
6600x2700x5370
|
6600x2700x5370
|
|
Total Weight(kg)
總重量
|
3050
|
3050
|
3320
|
3320
|
