膜寬（毫米）
Film width (mm)
|
50~320
|
|
制袋尺寸（毫米）長*寬
Bag size (mm) length * width
|
≤150*220
|
|
卷材直徑（毫米）
Roll diameter (mm)
|
≤400
|
|
包裝速度（袋/分鐘）
The packing speed (bags / minute)
|
50~95
|
|
電源總功率（千瓦）
Total power (kw)
|
2.5 kW 220/380 V±10% 50 Hz
|
|
機器尺寸（厘米）長*寬*高
Machine size (CM) length * width * height
|
110*80*160
|
|
整機重量（千克）
Machine weight (Kg)
|
≤250
|
適用范圍：
Scope of application:
本機適用于膨化食品、蝦條、麥片、瓜子、白糖、食鹽等松散無粘性粉狀、粒狀物料自動包裝;還適用于化工、藥品、茶葉、種子等物料的包裝。
This machine is suitable for puffed food, shrimp, oatmeal, melon seeds, white sugar, salt and other loose non adhesive powder, granular material automatic packing; also used in chemical, medicine, seed, tea packaging materials.
功能特點：
Function characteristics:
加料、制袋、充填、封口、裁切全自動完成，并帶有自動計數；配碳帶日期打印（如要充氮，可與充氮機匹配）；自動控溫，自動光電跟蹤，變頻無極調速。
Feeding, bag making, filling, sealing, cutting is finished automatically, and with automatic counting; with ribbon date printing (for example, nitrogen, and can be matched with a nitrogen filling machine); automatic temperature control, automatic photoelectric tracking, frequency conversion stepless speed regulation.
包裝材料：
Packaging.
紙/聚乙烯、玻璃紙/聚乙烯、聚酯/鍍鋁/聚乙烯、聚酯/聚丙烯、BQPP薄膜、尼龍/聚乙烯、茶葉過濾紙等熱封復合材料。
Paper / PE, Pt / PE, PET / Plated Al / PE, PET / PP, BQPP film, nylon / polyethylene, tea filter paper heat sealing composite material.
